CZL-24NCS vertical dual servo CNC gear hobbing machine

Machining accuracy：GB-5 level  Processing cycle time：4-15S  modulus：2.0mm

We have formed an integrated technical system that includes the manufacturing of gear hobbing machines, research on gear hobbing processes, and design and manufacturing of gear hobbing dies. We are committed to providing a complete set of solutions for various gear hobbing processes.

Multi stage digit control rubbing teeth

Fully CNC controlled, the machine tool can complete gear hobbing with different parameters at multiple positions on the same workpiece, saving operational procedures.

Servo front and rear roof structure

Adopting a customized 3210 screw rod, the front top adopts a cylinder method, and the rear servo motor is directly connected, effectively solving the problem of unstable accuracy during the tooth rubbing process.

Dual servo synchronization is more accurate

Driven by dual servo motors, it synchronizes more accurately and saves more than 70% energy compared to hydraulic drive. With intelligent full servo front and rear top technology, it effectively solves the problem of clamping.

High rigidity bed frame

HT300 cast iron bed body, connected by hexahedral frame bolts, has stronger overall rigidity and more stable processing.
